CROWN LIGHTING ST19 Infrared Security Motion Sensor
IP66 – 120 Degrees - Override - Black
CROWN LIGHTING ST19 Infrared Security Motion Sensor – IP66 – 120 Degrees
Specifications:
Power Source: 220-240V/AC
Power Frequency: 50/60Hz
Time Delay: Min.10sec±3sec Max.30min±2min
Detection Moving Speed: 0.6-1.5m/s
Installation Height: 1.8-2.5m
Detection Range: 120°
Detection Distance: 6-18m(<24℃)(adjustable)
Ambient Light: <3-2000LUX
Working Temperature: -20~+40℃
Working Humidity: <93%RH
Power Consumption: approx 0.5W
IP66 Weatherproof Rating
Vertical Installation
Wall / ceiling mount
Manual Over-Ride Instructions:
- 1) To operate as a light only , turn power off for 3 seconds and then back on.
- 2) To reverse the override function, turn power off for 10 seconds and then back on.
***This product must be installed by a licensed electrician***
(ST19-BLACK)
SKU | ST19-BLACK |
Barcode # | 9354506004798 |
Brand | CROWN LIGHTING |
